180 Degree Concealed Hinge

180° concealed hinge for doors that need to open fully. Suits 10mm maximum thickness door Parts 1x Printed parts (wood screw and euroscrew options available) 7x M4 30mm Countersunk screws needed 12x 1mm thick washers Assembly Print parts - no support needed. Wood screw option (3 holes) for standard screws, euroscrew option (4 holes) for special screws linked below Drill CSK and mid holes to 4mm to allow for good fit (holes are deliberately undersize) Tap M4 holes Assemble as shown in included PDF with washers inserted on each side of parts Euroscrew info - great for thin wood and chipboard. https://www.hafele.co.nz/en/product/euro-screw-haefele-varianta-countersunk-head-pz2-steel-for-screwing-into-wood/P-00900093/
