2 Piece Sample Filament Spool

Equilateral Triangle Filament Spool Updated 3 new v5 Requested by studiodave56 , who waned a spool for 1+ Kilograms of filament. Dimensions “ 200mm outer size with a 67mm total width and a 53mm inside hole ”. The image of the printed spool was supplied by him, as I did not print it myself. v5 - 200mm Outer DIA - 90mm Spool DIA - 53mm Inner DIA - 7mm Wide - Top v5 - 200mm Outer DIA - 90mm Spool DIA - 53mm Inner DIA - 60mm Wide - Bottom Updated 2 new v3 & v4 2 New version using less filament and have a uniform Thread. Both with the dimensions 180 MM Outer - 90 MM Center - 55 MM Inner Diameter. v3 - 180mm Outer DIA - 90mm Spool DIA - 55mm Inner DIA - Top v3 - 180mm Outer DIA - 90mm Spool DIA - 55mm Inner DIA - Bottom v4 - 180mm Outer DIA - 90mm Spool DIA - 55mm Inner DIA - Top v4 - 180mm Outer DIA - 90mm Spool DIA - 55mm Inner DIA - Bottom Original Versions 2 Versions of a 2 Piece Sample Filament Spool. The idea of the Hexagon spool is great but all those individual hexagons take forever to print. I though a repeating pattern of equilateral triangle would be quicker to print, give an interesting pattern, and allow for enough holes to thread the filament. v1 - 135mm Outer DIA - 55mm Inner Spool DIA - Top v1 - 135mm Outer DIA - 55mm Inner Spool DIA - Bottom v2 - 180mm Outer DIA - 75mm Inner DAI - Top v2 - 180mm Outer DIA - 75mm Inner DAI - Bottom All models were design in TinkerCad.
