Advanced Striker Chassis | Codeavour / RoboCup (DEMO PART)

Tired of just "pushing" the ball in Robo Soccer? Upgrade your game! Designed specifically for the 2026 Codeavour 7.0 - Track 3 competition, the "Advanced Striker Chassis" transforms your robot from a simple pusher into a strategic shooter. Key Features & Kinematics: Integrated Shooter Mechanism: Features a Crank-Slider system to shoot the ball from a distance. Omni-Directional Handling: 4-sided concave (oval) design allows 360° ball control using flanks and rear. Mecanum Ready: Perfectly optimized for crab/strafe evasion tactics and precise aiming without rotating the chassis. Competition Compliance (Track 3 Rules): Dimensions: Stays strictly within the 20 x 20 x 15 cm maximum size limit. Weight: Honeycomb structure ensures it stays well under the 800g limit. Legal Claw: Front design provides the mandatory minimum 14 cm clearance (no ball trapping). Required Hardware (BOM): 4x 6V 500 RPM DC Motors 4x 60mm Mecanum Wheels Standard N20 motor mounts (act as shock absorbers) This Printables download includes the Full Assembly/Gameplay PDF Guide and 3 DEMO PARTS (Motor Mount, Pin-24, and Coupling) so you can test the print quality. For the COMPLETE 3D printable chassis set with the mechanical shooter, please visit my Cults3D store: > https://cults3d.com/tr/3d-model/oyun/advanced-striker-chassis-codeavour-7-0-track-3-robo-soccer-mecanum-ready
