Chess board with annotations 3D model thumbnail

Chess board with annotations

by McMadness · via Printables
FormatSTL
CategoryOther
LicenseCC BY-NC-SA
UploadedJun 5, 2023
⬇ 216 downloads ❤ 14 likes 👁 1.1k views

Description

i printed the original chess board from @darthGinger and the chess pieces from @JacobG , i really liked the model but noticed to late that it missed the Algebraic notation. i desided to redesign the base to make it so there are 4 pieces instead of the original 16. besides that i added 5mm to the outer wall so i could fit the notations.i used “multimaterial painting” in prusaslicer to automaticly color these notations in (easier than you think). PRINT SETTINGS (PRUSA I3 MK3S + MMU2S): Infill 15% (gyroid) Layer height: 0.2mm ironing: topmost surfaces only (for me it came out better with this setting on but adds +-1 hour to each piece) support: no brim: no height range modifier: (i used 100% infill on the layer before it printed the notations, didn't test it without maybe you could save some time here) i'm pretty new to 3d-printing so i'm glad i got to do this as my first “project” if there is any additional file you want (step,prt,g-code,…) make sure to comment and i'll try to add those asap! PS: 100% scale = 78.74% from DarthGinger's set so the original squares etc fit
chess chessboard
