COREBOXX Heated Semi-smart add-on

The COREBOXX Semi-Smart is an advanced electronic upgrade for your filament storage system, enhancing usability, safety, and functionality. This modular system integrates filament chamber heating, real-time monitoring, and quick control options for an improved 3D printing workflow. 📷 Image redacted — claim this model to add your own media Key Features: ✅ Safe Filament Heating – 200W PTC heater with targeted temperature and humidity control (max 45°C) ✅ OLED Display – Shows current/set temperature, humidity, and custom messages like layer numbers ✅ RGB LED Control – Customized, gcode controlled lighting for your setup ✅ Enhanced Connectivity – 2 spare Prusa GPIO pins and an MMU easy-disconnect port ✅ User-Friendly Controls – Quick-access buttons for adjustments ✅ Future functions in mind – like Servo control Video; Modular Design for Easy Assembly: 🔹 Semi-Smart PCB – The core control board 🔹 Heater Assembly – Efficient heating with safety measures 🔹 HMI Module – Interactive display and button interface 📷 Image redacted — claim this model to add your own media Electronics & hardware kit; Electronics are easy to use and are the way-to-go for a plug-and-play system. However, they are expensive and only cost-effective in larger quantities. Therefore, I worked together with Blurolls store to offer kits worldwide for a price lower than you can source yourself! Currently, we only sell through the direct store of BLUROLLS, but later we will also stock the kits in the USA and Germany, and sell through AliExpress. Link to the kit: (€85) Prusa Core One Coreboxx Electronics Semi-smart addon Ecosystem kit Building manual; A full, detailed, and step-by-step build and user manual can be found here Technical Specifications: Power: 250W | Voltage: 24V Heating: Max 45°C, integrated safety limits (10A fuse, 60°C thermal fuse) PCB Layers: 4 (Main) | 2 (HMI) Dimensions: Semi-Smart PCB: 71mm × 74mm HMI PCB: 16.5mm × 75mm Heater Unit: 125mm × 117mm × 59mm Remixing; I encourage you to play with the designs and code to add whatever you find missing for your setup! Some Ideas I have already seen online are mounting for MK/XL/Mini enclosure, different (touch) screens, print removal via the servo, or added functions on the OLED/ buttons. You can find the full source code in the files below, along with the PCB schematic and pinout. If you have adapted something, please make sure to post it as a remix for others to find! :) 📷 Image redacted — claim this model to add your own media Firmware; Firmware is developed by @3DMonkey in cooperation with Voxel3D 📌 For personal use only – Commercial production, sales, or distribution is not allowed without prior consent from the designer.
