Definitive Collection of Battery Holders (Gridfinity, Stackable & Labelled)

The containers are designed to be used independently or with Gridfinity baseplates . The bottom has magnet holes for magnetized Gridfinity baseplates. The containers when fully loaded are stackable. The battery model number is printed on the outsides and the insides whenever feasible. The design tries to find the best trade-off between container's capacity, usability, stackability and robustness. Gridfinity specifies container sizes with atomic increments of 42mm for the width (X) and the depth (Y), of 7mm for height (Z). For instance, a 1x2x4 Gridfinity container has sizes of 42mm x 84mm x 28mm. For large batteries, the following dimensions are available (1x1, 2x1 and 2x2). When the battery is too tall, there is also a low clearance version. This is intended to fit in shallow drawers. 1x1 and 2x1 containers can stack on top of most 2x2 containers. If that is not the case, you may use these stackable baseplates by Akio (thanks @avx for suggesting the idea). For cell batteries, there are 2 container sizes: 1x1 and 2x1. Let me know: if you cannot find a container for your battery type, if you encounter a fitting or usability problem, if you have any suggestions. List of containers Meaning of filename: ModelName - xNN - grid XYZ - vR.r where: NN is the capacity X is the X width gridfinity block count (multiply it by 42mm to get the size) Y is the Y width gridfinity block count (multiply it by 42mm to get the size) Z is the height grdifinity block count (multiply it by 7mm to get the size) R.r is the version number Battery TypeCapacityGridfinity Size 14250 aka CR14250 & ER14250 51x1x5102x1x5242x2x51850041x1x882x1x8162x2x81865022x1x441x1x1042x2x482x1x10162x2x102170021x1x1032x2x442x1x1192x2x11½AA41x1x5102x1x5242x2x59V21x1x852x2x562x1x8122x2x8 A23 aka 1181A, 144, 23A, 23AE, 3LR50, 8F10R, 8LR23, 8LR932, A23S, CA20, EL12, E23A, GP12A, GP23, GP23A, K23A, L1028, LR23A, LRV08, MN21, MN23, MS21, P23GA, RVO8, VR22, V23GA 91x1x5212x1x5482x2x5 A27 aka GP27A, MN27, L828, 27A, V27A, A27BP, G27A, 8LR732 161x1x5362x1x5802x2x5AA51x1x8102x1x8242x2x8AAA91x1x7212x1x7362x2x7AAAA161x1x7322x1x7642x2x7B12x1x421x1x1032x2x442x1x10122x2x10C11x1x832x1x842x2x582x2x8 CR2 aka 15270, 15266, CR15H270, 5046LC 51x1x5102x1x5192x2x5 CR123A aka CR123, 123, 123A, 16340, 17345, 2/3A, BR2/3A, CR17345, CR23, DL123A, EL123A, K123LA, L123A, SF123A, VL123A 41x1x682x1x6162x2x6D11x1x1012x1x622x1x1022x2x652x2x10 N aka LR1, MN9100, AM5, GP910A 91x1x3182x1x3362x2x3 For CRxxxx, AGx and LRxx button cell holders, please go to these posts: CRxxxx Button Cell Battery Holders (Gridfinity, Stackable, Labelled) AGx Button Cell Battery Holders (Gridfinity, Stackable, Labelled) LRxx Button Cell Battery Holders (Gridfinity, Stackable, Labelled) Credits: These works were based upon: Zach Freedman's initial designs of Gridfinity. "Gridfinity: Your Ultimate Modular Workshop is FREE!" Gridfinity Unofficial Community Overkill Gridfinity Baseplate by Kyle Warren These works are written using: OpenScad Gridfinity OpenScad Model by Jamie Write.scad by Harlan Martin
