Desk stranding wall mount & short arms
by Sperd · via Printables
| Format | STL |
| Category | Mechanical |
| License | CC BY-NC |
| Triangles | 8.2k |
| Uploaded | Jan 21, 2022 |
⬇ 72 downloads
❤ 23 likes
👁 857 views
Description
This is a remix of the desk stranding lamp which can be found at: https://www.prusaprinters.org/prints/40386-desk-strand Thank you so much Nils Kal for making this awesome design! All other parts can be found in the link above. I wanted to remix this design so that it would fit my set up and could be used with the electrical components that I had laying around. I would love to see your makes! The changes I made are: The arms are way smaller and the holes are enlarged to 6mm. I also removed the hexagonal embossment. The connectors have enlarged holes of 6mm. The main body has holes for a 6mm switch and a 12v adapter plug. the original switch hole was covered up. The LED hole in the front was replaced to fit the IR sensor of the LED strip controller. A wall mount was designed that fits the arms (print this at 100% infill). I also uploaded it on Thingiverse: https://www.thingiverse.com/thing:5208145
Originally published on Printables
