Dyna Dry Box - Modular Remix

I liked a lot the "Dyna Dry Box" but I had few constrains: 1. I wanted the silica box to be detachable so I can print it in ASA 2. The detachable box needs more breathable structure or a bit bigger form 3. I needed an option to add different types of humidity sensors 4. I had 688zz bearings (16x8x5), so I want to use this instead of 608zz bearings (22x8x7) 5. My filament roll has diameter of 67mm width So I changed the original by making it modular, there is base, silica box and sensor support. Base , three 7x2mm magnets are required to be inserted in designed locations. 📷 Image redacted — claim this model to add your own media Silica box , I have used three steel M3 nuts, but 6x2mm magnets can be also used. 📷 Image redacted — claim this model to add your own media Sensor support, M3 screws can be used to secure sensor support to base (in my experience it's not needed). There is a horizontal weak line that can be cut if the print is too tight (in my experience it's not needed) 📷 Image redacted — claim this model to add your own media 📷 Image redacted — claim this model to add your own media Note: There is a correct direction to print this, print as loaded or search for triangle where cut line is (triangle needs to be printed point down) Sensor Parts : Round Sensor Square sensor Roll , I have 2 roll variants redesigned to accommodate 688zz bearings (16x8x5) 1. It's basically a remake of the original to accommodate 688zz bearings - MAX 65mm 2. It's a more tight a bit longer version to accommodate 67mm wider rolls Note: use 2nd variant only if you have a wider roll, USE original if you have 608zz bearings Print suggestions: I have printed the silica box in ASA, anything else in PLA. Nozzle size: 0.4 Layer height: 0.2 (sensor supports are printed best with 0.16)
