Electrical Tape Dispenser  3D model thumbnail

Electrical Tape Dispenser

by laythrom · via Thingiverse
FormatSTL
CategoryGadgets
LicenseCC BY-NC-SA
Triangles1.7k
UploadedMar 5, 2026
⬇ 60 downloads ❤ 3 likes 👁 121 views

Description

I needed a way to quickly cut strips of electrical tape for wiring harnesses and I got a little tired of using scissors. I attempted to use a plain 'office tape dispenser' (used for Scotch tape) but the rolls of electrical tape are too large in diameter, so I decided to make my own. At the moment, this design uses a single sided razor blade to cut the tape (I might try to use a hacksaw blade or something that's not as slicey-dicey, but I had a bunch of razor blades from cutting heat shrink tubing, so I just used that). The bottom of this dispenser is also modeled to accept 6-32 heat set threaded inserts so that I could bolt it to my workbench. The print is very light and with the additional force required to pull on electrical tape (when compared to Scotch tape), a weighted base still wasn't enough. I've included the Fusion exports in case someone wants to put their own spin on things.
electrcial tape industrial tape dispenser tape dispenser tape dispenser core
