Ender 3 V3 KE LCD Reposition Stand 3D model thumbnail

Ender 3 V3 KE LCD Reposition Stand

by Uncle Bubby · via Printables
FormatSTL
CategoryArt
LicenseCC BY-SA
Triangles2.0k
UploadedMar 5, 2024
⬇ 427 downloads ❤ 37 likes 👁 2.1k views

Description

First, I needed to reposition the LCD on an Ender 3 V3 KE. The slots and posts are reversed from the SE (the slots on the KE are on the LCD) and I was unable to find an alternate LCD mount for the KE. TinkerCAD had a hard time with modifying the model. For some reason gaps would appear in the model when I tried to merge any changes so I started from scratch and used the original for a template. I moved the spool holder to the side and because I have my printer lifted up on a set of drawers I needed to extend the mount downward. This put the LCD in the way of the spool. This mount lifts the LCD up so the lowest part of the control box is about even with the top of the printer base. It also changes the angle to a higher 40 degrees.
mount lcdmount mountingbracket controlpanel ender3v3ke reposition
