EVA 3 Inlet for Dual EBM-Papst RLF 35-8/14 N

This is a EVA 3 fan inlet for two RLF 35-8/14 N fans from EBM-Papst . Use two M3x6 or M3x8 countersunk screws to attach the inlet to the EVA 3 back. To secure the fans, you can use two M3xD4.6xL4 heat set inserts in the center arm of the inlet and two M3x20 screws from each side. It is also possible to use one M3x50 screw and hex nut instead. For additional stability, you can use the optional spacer on the top holes of the fans to connect them together. Use two M3xD4.6xL4 heat set insert in the spacer and two M3x16 or M3x18 screws from each side. It is also possible to use one M3x45 screw and hex nut instead.
