GOEWS VESA monitor and mini PC mount

This is a VESA mount for GOEWS allowing mounting of monitors and mini PCs on GOEWS walls. Unlike other wall systems, GOEWS is strong enough to easily handle things like monitors. With this mount installed you can simply pick up the monitor and place it anywhere you like. Since mini PCs often use the same VESA mounting holes, this mount can be used for those as well. Required hardware 4 M4x12mm DIN 7991 flat head cap screws Printing If you use the the hexagonal GOEWS tiles print parts A and B . If you use the GOEWS GRID tiles print part A twice. If you use the “thicker cleats” variant of GOEWS use the “thicker cleats” parts. How these were generated In case you wanted to customize, these were generated using https://goews.funktronics.ca/ with the following settings: Part A: Part type: Hanger mount First hole Hole type: Countersink for FHCS X offset: 12.5 Y offset: 18 Diameter: 4.1 Depth: 5 Second hole Hole type: Countersink for FHCS X offset: 112.5 Y offset: 18 Diameter: 4.1 Depth: 5 Plate thickness: 6 Bolt notch disabled Part B: Part type: Hanger mount First hole Hole type: Countersink for FHCS X offset: 33.5 Y offset: 9.5 Diameter: 4.1 Depth: 5 Second hole Hole type: Countersink for FHCS X offset: 133.5 Y offset: 9.5 Diameter: 4.1 Depth: 5 Plate thickness: 6 Bolt notch disabled
