Hadley Dovetail Mount
by Twiegel · via Printables
| Format | STL |
| Category | Mechanical |
| License | CC BY-NC-SA |
| Triangles | 99.4k |
| Uploaded | Jul 24, 2025 |
⬇ 39 downloads
❤ 4 likes
👁 368 views
Description
I needed a ¼ inch thread to mount the Hadley on my star tracker so I created these low profile adaptor rings to use the SVBONY universal dovetail plate. It features all the relevant threads and provides an upgrade path for the use with better goto mounts etc. My print settings: PLA 5 walls 25% infill They are really sturdy and sit just shy of the original bearing mount, making it possible to switch between the original and tracking mount without any disassembly. Dovetail link: https://www.svbony.com/svbony-dovetail-mounting-plate/#W9175C
AI Analysis: This object is a mechanical mount designed to securely hold a telescope or similar optical instrument. It features a robust structure with adjustable clamps and a dovetail joint to ensure stability and precise alignment. The mount is constructed from durable materials and includes a circular base for stability.
