HMB Endeavour Elements (model-shipyard.com)

📷 Image redacted — claim this model to add your own media Overview This is unofficial set of decoration elements, armament and laser-cutting templates for Shipyard's paper model in 1:96 scale: HMB Endeavour I update the models quite often, introducing fixes and improvements, so before printing, please check for the latest version on Thingiverse again. These models are designed for printing on a UV LED resin 3D printer. Some parts need to be slightly bent before gluing. To do this, place the part in hot water (up to 100°C) for a few minutes, then bend it, checking the fit against the mounting location. To determine the quantity of parts, refer to the "BOM: Thing Elements" section. Some parts are symmetrical for the right and left sides of the model and need to be mirrored. For such parts, the "R+L" column in the "BOM: Thing Elements" table will show the value "R+L" - please take this into account when preparing the print. Additional rigging elements are available separately and can be downloaded via the link in the "BOM: Rigging Elements" section. You can also download vector files for laser-cutting the frame parts and deck elements. These files are located in the laser_cut.zip archive. For more details, please refer to the "Notes: Laser Cut" section. 📷 Image redacted — claim this model to add your own media Notes: Laser Cut Files naming convention for laser_cut.zip package: deck.svg - wooden veneer laser cut parts thinckness_0_5.svg - 0.5 mm cardboard parts thinckness_1_0.svg - 1.0 mm cardboard parts thinckness_1_5.svg - 1.5 mm cardboard parts thinckness_2_0.svg - 2.0 mm cardboard parts Color convention: black layer - Dark engraving of deck planks blue layer - Nails on deck engraving (should be less dark than black layer) purple layer - Cut-through lines red layer - Labels and markdowns engraving layer BOM: Rigging Elements Rigging elements are in the separate thing: https://www.thingiverse.com/thing:7297386 Number of sets and sizes you need for this model: Part # Count Sets Description 255 66 7 Deadeye 3.5mm 256 60 6 Deadeye 3.0mm 257 20 2 Deadeye 2.5mm 258 46 5 Single block 4.0mm 259 110 11 Single block 3.0mm 260 2 1 Heart block 4.0mm 260a 4 1 Heart block 5.0mm 260b 4 1 Heart block 4.5mm 261 14 2 Duck 5.0mm BOM: Thing Elements Description of columns: Sym - symmetrical should be mirrored to get left or right parts R+L - number of mirrored groups of parts Total Count - total number of parts Part # Sym R+L Count Total Count rz R+L 1 2 gl - - 2 91a - - 1 91ba - - 4 136a R+L 1 2 137a R+L 1 2 151 - - 6 152 - - 2 154 - - 1 263 - - 10 265 - - 1 📷 Image redacted — claim this model to add your own media
