HMS Revenge Ship Elements (model-shipyard.com)

📷 Image redacted — claim this model to add your own media Overview This is unofficial set of decoration elements and armament for Shipyard's paper model in 1:96 scale: HMS Revenge https://model-shipyard.com/en/paper-models/422-elizabethan-galeon-revenge-1588-5902574600103.html I update the models quite often, introducing fixes and improvements, so before printing, please check for the latest version on Thingiverse again. These models are designed for printing on a UV LED resin 3D printer. Some parts need to be slightly bent before gluing. To do this, place the part in hot water (up to 100°C) for a few minutes, then bend it, checking the fit against the mounting location. To determine the quantity of parts, refer to the "BOM: Thing Elements" section. Some parts are symmetrical for the right and left sides of the model and need to be mirrored. For such parts, the "R+L" column in the "BOM: Thing Elements" table will show the value "R+L" - please take this into account when preparing the print. Additional rigging elements are available separately and can be downloaded via the link in the "BOM: Rigging Elements" section. You can also download vector files for laser-cutting the frame parts and deck elements. These files are located in the laser_cut.zip archive. For more details, please refer to the "Notes: Laser Cut" section. Notes: Laser Cut Files naming convention for laser_cut package: deck.svg - wooden veneer laser cut parts thinckness_0_5.svg - 0.5 mm cardboard parts thinckness_1_0.svg - 1.0 mm cardboard parts thinckness_1_5.svg - 1.5 mm cardboard parts thinckness_2_0.svg - 2.0 mm cardboard parts Color convention: black layer - Dark engraving of deck planks blue layer - Nails on deck engraving (should be less dark than black layer) purple layer - Cut-through lines red layer - Labels and markdowns engraving layer BOM: Rigging Elements Rigging elements are in the separate thing: https://www.thingiverse.com/thing:7297386 Number of sets and sizes you need for this model: Part # Count Sets Description B1 4 1 Single block 4.0mm B2 49 5 Single block 3.0mm B3 100 10 Single block 3.5mm B4 4 1 Long tackle block 5.0mm B5 4 1 Long tackle block 5.0mm B6 2 1 Triple ramshead block 5.0mm B6 2 1 Triple ramshead block 5.5mm V 20 2 Duck 4.0mm J1 67 7 Triangle deadeye 3.0mm J2 50 5 Triangle deadeye 2.5mm J3 21 3 Triangle deadeye 2.0mm BOM: Thing Elements Description of columns: Sym - symmetrical should be mirrored to get left or right parts R+L - number of mirrored groups of parts Total Count - total number of parts 📷 Image redacted — claim this model to add your own media Part # Sym R+L Count Total Count figurehead - - 1 113 - - 1 146 R+L 1 2 147 R+L 1 2 148 - - 1 206 - - 2 207 - - 2 208 - - 2 248 - - 1 274 - - 4 275 - - 10 276 - - 2 277 - - 6 278 - - 10 279 - - 2 280 - - 2 281 - - 4 282 - - 4 283 - - 16 J4 - - 2 J5 - - 2
