Magnetic left window for Prusa Enclosure V2 - MMU2S 3D model thumbnail

Magnetic left window for Prusa Enclosure V2 - MMU2S

by [email protected] · via Printables
FormatSTL
CategoryArt
LicenseCC BY-NC
Triangles2.7k
UploadedJul 12, 2023
⬇ 59 downloads ❤ 18 likes 👁 745 views

Description

Why A many others I really like Prusa Enclosure V2, but one of the biggest pain points is terrible access to printer as power cables and PTFE tubes holds printer inside and especially any work in box with electronics is just hell… How For this reason I decided to adjust the frame little bit to allow opening of left plexi glass. Plexi glass is hold by magnets now, so you can always push it away and click it back when needed. It is designed in a way it requires re-print for only 4 plastic pieces (+1 optional, more info later). Pieces Remix adjusted 4 corner pieces holding the plexiglass by splitting each of them into holder of plexi glass and frame part. Holders are triangle parts glued to plexi glass holding magnets. Frame parts are original structure adjusted for being able receive holders + added magnet. Optional pieces Top middle part frame and holder are optional to print. Without them: You'll be forced to open window from bottom first as original middle pieces will hold plexi glass on top. With them: You can open plexi glass as you wish (but it'll be little bit harder for glueing). Magnets I used N48 magnets 20x5x3 mm as I had them home, thou it's overkill. Feel free to use lower quality magnets or smaller magnets (smaller magnets will require glueing as frame is design for this dimension).
prusa window enclosure magnetic
