Mellanox ConnectX-4/ConnectX-5 Full Height Bracket 3D model thumbnail

Mellanox ConnectX-4/ConnectX-5 Full Height Bracket

by slumcum · via Thingiverse
FormatSTL
CategoryMechanical
LicenseCC BY-SA
Triangles1.8k
UploadedApr 7, 2026
⬇ 7 downloads 👁 28 views
⬇ Download STL 👁 View Details

Description

I needed a few extra Full-Height brackets for a project, could not find any so I made my own, modeled after the OEM bracket, with a few tweaks to increase the structural rigidity This should fit Mellanox ConnectX-4 MCX416A MCX456A / Mellanox ConnectX-5 MCX556A MCX516A dual port QSFP cards I printed out of ASA, its been in the hot aisle of a data center for months without any issues Supports required, I used Tree Hybrid
hpc Infiniband bracket networking QSFP QSFP bracket server

Originally published on Thingiverse
