Morse Code paddle/ CW Key (basic components)
by VladTheInhaler · via Printables
| Format | STL |
| Category | Other |
| License | CC BY-NC-SA |
| Triangles | 13.6k |
| Uploaded | Sep 21, 2025 |
⬇ 14 downloads
❤ 6 likes
👁 311 views
Description
I didn't have any of the components listed in the BOM and I really just needed something to tinker with on the breadboard while developing my bluetooth controller/keyer for morse mania. I kept running into issues with the screws shearing my braided wires when building it per the original instructions. So I added holes to the paddle to allow me to route the wires externally and connect via a nut on a longer bolt. It works super well. not sure if this will help anyone but all you need is some wire and 3m bolts/nuts.
AI Analysis: This is a Morse code key used for sending telegraph signals. It contains electronic components and wiring to convert manual key presses into electrical pulses. The device features a circuit board with integrated chips and multiple colored wires connecting to a connector.
