Motorized Mini Desktop Escalator

Update: I've released a completely reworked version of this design which comes with a whole host of improvements. Check it out here: https://www.printables.com/model/912094-motorized-escalator-model-redux This is a motorized version of my mini escalator design. Latest Fusion 360 file: https://a360.co/38LBZJZ You will need: 19 M3x12mm bolts 18 M3 nuts N20 geared motor, 30RPM 6V TP4056 battery charging board (USB C preferred) 18650 battery and holder (pouch cells probably work too, just need to find one that fits) DPDT 3-position On-Off-On toggle switch Wires Hot glue or double sided tape, to attach battery holder and charging board Assembly is essentially the same as the non-motorized version, and parts are generally cross-compatible. Make sure to install the motor onto the right side outer guide before attaching the guide to the rest of the escalator. Will add a more detailed set of assembly instructions when I find the time, likely in video form. Category: Buildings & Structures
