Motorized Pictionary

The three .stl files can be used to 3D print directly. If you want to make edits, the .FCStd file can be used in FreeCAD while the .step file can be used in a CAD file of your choice. Dimensions is roughly an octagon with a 9" (228 mm) diagonal, and 30 mm depth. The space inside is an octagon that with a 214 mm (8.4") diagonal, and about 1 inch (25.4 mm) in depth. Screw holes are 1 mm (to be tapped) and 2 mm clear hole, but 3D printer will likely print smaller diameters. May need to manually drill and tap. The drawing plate hexagonal coupling is 14 mm vertex-vertex diagonal (inner) and 20 mm vertex-vertex diagonal (outer), and a 12.7 mm length Things to add: Cut out for slider or switch Battery Compartment for AA (2 - 4 as needed to power motor) Motors, gears, mounts Electronics and cables
