Multiboard bottle holders with Multipoint connector rails

Multiboard bottle holders in sizes from 20mm to 150mm. The flask / bottle holders uses the Multipoint connectors. Use one of the many connector types to mount the bottle holders to the Multiboard . The bottle holders has the same OXO rail as is used by the Multiboard bins. For more information regarding the multipoint connectors, see this Video Tutorial Recommended print settings (same as multiboard defaults): 3 wall perimeters in wall thickness 15% infill No supports needed 0.2 mm layer height 0.40 mm nozzle PLA Notes for the parametric Autodesk Fusion model The parametric model includes one of Jonathans ( KeepMaking ) Multipoint connectors as a component, this means that you cannot just select File>3D Print from Autodesk Fusion. File>3D Print cannot merge the flask holder to the connector. To get the entire model ready for the slicer choose File>Export and select .stl in Autodesk Fusion. Parameters: diameter - Flaskholder diameter. tolerance - Tolerance added to the diameter. wall - The flaskholder wall thickness. height - The flaskholder height. But note that the Multipoint connector component cannot be resized by this parameter. Special thanks to Jonathan ( KeepMaking ) for creating multiboard . Change log: 25-Jan-2025 - Added parametric Autodesk Fusion model.
