Raspberry Pi 5 based 5-Bay NAS

Remixed version of the 4-bay NAS in Maker World to take 5 drives along with some other quality-of-life improvements. Original design: https://makerworld.com/en/models/1605027-raspberry-pi-5-based-4-bay-nas Assembly and part requirements are nearly identical to the original. My blog post about the changes can be found here: https://neildutoit.co.za/2026/pi-nas.html Body Back Main.3mf has modifiers to increase infill density around brass inserts. I printed in PETG since hard drives can become a bot warm and I didn't want to risk PLA warping. 0.20mm Structural on Core One with 15% gyroid infill Print list (~1.25kg filament): 1x Body Back Main (80% gyroid infill around brass inserts) 1x Body Back Lid 1x Fan cover 1x Body Front 5 Bay 1x SATA Holder Bot (3x perimeters for extra strength) 1x SATA Holder Top (3x perimeters for extra strength) 5x Sata Holder insert (3x perimeters for extra strength) 5x Drive Tray 5x Drive Tray Handle - Blank 5x Drive Tray Handle - Blank 03-03-2026: Add Drive Tray Reinforced
