Rocketdine F1 engine 1:10 3D model thumbnail

Rocketdine F1 engine 1:10

by Martijn Schuman · via Printables
FormatSTL
CategoryMechanical
LicenseCC BY-NC-SA
Triangles17.6k
UploadedNov 6, 2024
⬇ 205 downloads ❤ 47 likes 👁 1.9k views

Description

I decided to scale the model to be 1:10. In order to print it on my Ender 3 V2 I had to split a couple of the STL files. The files, ‘F-1_Powerpack’ and ‘F-1_Outrigger’ have to be scaled to 227,90%. The ‘F-1_Powerpack’ STL file had a couple different parts, so depending on the printer, you have to split the model. I used the Mesh Tools extension in Cura to split the model in separate parts. If you have an Ender 3 V2 with the default build plate clips, be careful, because the model is just big enough for the build plate. I had to move the clips to the corners in order to fit the model. ‘F-1_Nozzel_bottom_right v1’ and ‘F-1_Nozzel_bottom_left v4’ have to be rotated by 45°, otherwise they're too big. I added the Fusion360 3MF files if you have to change anything
f1 rocketengine rocketdine
