SSD with enclosure for 19 inch server rack 1 U installation
by Ragzee · via Thingiverse
| Format | STL |
| Category | Mechanical |
| License | CC BY-SA |
| Triangles | 23.1k |
| Uploaded | Mar 30, 2026 |
⬇ 2 downloads
👁 14 views
Description
A front-loading push-in tray for a cased 2.5" SSD enclosure in a 1U rack plate. The drive enclosure slides in from the front and is held by side rail lips and a rear backstop. Two front flange ears with M3 through-holes fasten the tray flush to the rack plate face. Designed to mount 4 units side-by-side in a standard 1U rack (424 mm total, fits within the 482 mm 1U inner width with room to spare).
Originally published on Thingiverse
