THE 100 CYD with Hinge

Thanks to Dsk001 for the beautiful case and Matt The Printing Nerd for the great THE 100. I added the holder to the Frame Connector Front 1 for THE 100. The holder on the connector now has a hole for M 3 BOM heat inserts. On the hinge I added a hole for M 3 screws and a cutout for a fixing stone. Thanks to the fixing stone and the M 3 screws, the CYD is held perfectly from both sides. I removed the sign on the front of the case. My CYD has an additional USB C port, and the USB Micro port is offset 2 mm outwards. I adapted the “Front USB C” and “Back USB C” parts so that both USB ports can be used. I countersunk the screw heads; M 3x12 cylinder screws are required. After replacing the connector you can mount the CYD (ESP32-2432S028R). Additionally required: 2 (THE 100 BOM) heat inserts and 2 screw M3x16 Cheap and easy Klipper touch interface with CYD Klipper https://www.youtube.com/watch?app=desktop&si=kFc3SM4T4P940WiQ&v=R3o0MGYW1ZU&feature=youtu.be CYD-Klipper https://github.com/suchmememanyskill/CYD-Klipper/blob/master/README.md ESP32-Cheap-Yellow-Display https://github.com/witnessmenow/ESP32-Cheap-Yellow-Display#where-to-buy THE 100 v1.1.0.1 - Over 90 modified and new parts made. https://www.printables.com/de/model/596834-the-100-v1101
