Universal Tip‑to‑Open Mechanism

This is a universal, adjustable tip‑to‑open mechanism designed to be mounted on any wooden board inside a cabinet. Simply attach it, and it works as a reliable push‑to‑open solution for doors or drawers. The hook element is fully replaceable , making the system long‑lasting and easy to repair. Features Replaceable hook for long‑term durability Available in 1 mm increments from 10–25 mm Base and slider rod print without supports Hook requires minimal support Two slider versions included: Standard slider Slider with rubber foot Compact, universal design suitable for most cabinet setups Remix of an existing mechanism — original creator is credited for the functional concept Printing Recommendations Part Supports Notes Base No Print flat for strength Slider No Choose version based on your application Rod No Smooth print improves sliding Hook Yes Only small supports needed Printed and tested with 0.2mm PETG GEEETECH Required Hardware Compression spring: 9 × 35 mm Countersunk screw: M3 × 10 mm Rubber feet: 6mm Link Assembly Overview Print the base, slider, rod and hook. Insert the 9×35 mm compression spring into the slider channel. Insert the slider + Spring into the base Screw on the rod to the base while the pin is in the path on top of the slider Slide the Hook onto the base Choose your preferred slider version (standard or rubber‑foot). Adjust hook length (10–25 mm options) to match your cabinet geometry. I recommend to add a drop of lubricant for the mechanism to work smoothly. Credits This model is a remix . The mechanism concept is based on the work of the original creator, who deserves full recognition for the underlying design idea. (Original link will be added.) Model: Creator: https://www.printables.com/@A548
